Cabinet Solutions for Verizon



(search by Material ID, CLEI, Model or Description)


Jump to:

1. Nortel OPAC / OPM

5. Litespan 2016

9. Mesa XL (Cell Site)


2. Nortel DMS OPM

6. Mesa 2

10. SLC96 (36 Type)


3. 80 Type / SLC 2000

7. Mesa 4

11. 36B


4. LS2000

8. Mesa 6 (Marconi)

12. Marconi ECU


TAG OSP Replacement Fans (.pdf)

Description:
 42 Page booklet w/ Material ID #'s for
NEW OSP Cabinet / Tray Replacement Fans
provided by TAG, Inc.

Last Update: 07/02/24, (Rev.66)




1

Nortel OPAC / OPM Cabinet Solutions (.pdf)

# TF-NTOPAC
 48V Fan for Nortel OPAC / OPM Cabinet

 # TF-NTOPAC-02
 48V Fan for Nortel OPAC / OPM Cabinet

 (Inner Roof of Cabinet) - 8 or 12 per cabinet
(Internal Tray Fans) - 2 per tray

return to top



Nortel DMS OPM Cabinet Solutions



2

Nortel DMS OPM Cabinet Solutions (.pdf)

# TF-DMS06
48V Fan for Booster Fan Unit (BFU) found in DMS OPM Cabinets
 (BFU Fans) - 3 per cabinet
# TFR-8X06ABT
 TAG Refurbishing - Paddleless Alarm Conversion Upgrade for NT8X06AB Fan Trays found in DMS OPM Cabinets
 (Internal Trays) - 2 trays per cabinet

return to top





3

80 Type - SLC2000 Cabinet Solutions (.pdf)


# TF-SLC201-02
48V Heat Exchanger for 80 Type Cabinet
 (Side of Cabinet) - 2 per cabinet


# TF-SLC201
48V Fan for SLC 2000 4A / 4B Fan Trays

(Internal Tray Fans) - 2 per tray


 # TFC-114A-01
114A Fan Control Unit for80 Type Cabinet Heat Exchangers
 (Heat Exchanger Controller) - 1 per cabinet

 # TFC-LU4-01
 Alarm Control Board for Lucent 4A / 4B, 4G / SLC 2000 Fan Trays & 114A Control Units

(Tray Controller Board) - 1 per tray/controller

 # TF-SLCBC-01
48V Cooling Fan for 80 Type Cabinet Battery Compartment

- 1 per cabinet


# TFC-116A-01
Alarm Control Board for Lucent 116A Battery Fan Unit
(Control Board)

- 1 per cabinet

return to top




4

LS2000 Cabinet Solutions (.pdf)

# TF-LS2000-03
 48V Heat Exchanger for Litespan 2000 Cabinet Heat Stack
 (Top & Bottom) - 2 per heat stack
# TF-LPM-01
 48V Fan for Lorain Power Modules
 - approx. 3 per cabinet

 # TF-LS2000-44
 Litespan 2000 DFA Fan Kit
 (Internal Tray Fans) 1 Kit (4 fans) per tray
(3 KITS = 12 FANS)

 # TFC-DFA-01
 Alarm Control Board for Litespan 2000 DFA Fan Tray
 (Fan Tray Alarm Board) - 1 per tray

return to top





5

LS2016 Cabinet Solutions (.pdf)


# TF-LS2000-03
 48V Heat Exchanger for Litespan 2016 Cabinet Roof HX Assembly

(Roof HX) - 6 per cabinet

 # TF-LS2000-44
 Litespan 2016 Cabinet DFA Fan Kit
 (Internal Tray Fans) - 1 Kit (4 fans) per tray
(4 KITS = 16 FANS)


# TFC-DFA-01
 Alarm Control Board for Litespan DFA Fan Tray

(Fan Tray Alarm Board) - 1 per tray

 # TF-LS2000-02
48V Fan for Litespan 2016 Cabinet High Velocity PDFA Tray

(Internal Tray Fans) - 3 per tray



# TFC-PDFA-01
 Alarm Control Board for Litespan High Velocity PDFA Fan Tray

(Fan Tray Alarm Board) - 1 per tray

return to top




6

Mesa 2 Cabinet Solutions (.pdf)

 # TF-MC225-01
(225mm) Heat Exchanger
(Top Solar Panel Fan) - 1 per cabinet

 # TF-MC225-02-KIT
(225mm) Heat Exchanger KIT
(Bottom Internal Fan) - 1 per cabinet

return to top




7

Mesa 4 Cabinet Solutions (.pdf)

 # TF-MC225-01
(225mm) Heat Exchanger
(Top Solar Panel Fan) - 2 per cabinet

 # TF-MC225-02-KIT
(225mm) Heat Exchanger KIT
(Bottom Internal Fan) - 2 per cabinet

return to top




8

Mesa 6 (Marconi) Cabinet Solutions (.pdf)

 # TF-MESA6-01
48V Heat Exchanger for Marconi Mesa "Bottom" HX Cabinet
(Bottom Heat Stack Fan) - 4 per cabinet

# TF-MCABTZ-01
48V Heat Exchanger for Marconi Mesa "Top" HX Cabinet (Tarzan)
(Top Heat Stack Fan) - 2 per cabinet

# TF-FA400-01
48V Fan for Marconi Mesa Master Fan Tray
 (Internal Tray Fans) - 4 per cabinet

# TFC-FA400-01
 Alarm Control Board for Marconi Mesa Master Fan Tray
 (Fan Tray Alarm Board) - 1 per tray

# TF-FA400-02
48V Fan for Marconi Mesa Slave Fan Tray
 (Internal Tray Fans) - 12 per cabinet


return to top




9


Mesa Cell Site Cabinet Solutions (.pdf)

 # TF-MC225-01A
 (225mm) Heat Exchanger for Cell Site Emerson Mesa XL Cabinet Door
 (Top Left & Lower Right) - 2 per cabinet
# TFC-MESA-01
 Alarm Controller for Mesa Cabinet
(Inside Door) - 1 per cabinet

return to top




10

SLC96 (36 Type) Cabinet Solutions (.pdf)

# TFT-SLC96-AC01
110VAC Fan for SLC96 (36 Type) Cabinets
w/ Bracket Assembly

 # TF-SLC96-AC02
110VAC Fan for SLC96 (36 Type) Cabinets
(fan only)

(use in Fan Assembly KS22099L5 found in 36 Type Cabinets)

return to top





11

36B Cabinet Solutions (.pdf)

# TF-LU2C
48V Fan for Lucent 2C Fan Unit / Tray
(Internal Tray Fans) - 3 per tray

# TFC-LU2BC-01
 Alarm Control Board for Lucent 2B & 2C Fan Trays

(Fan Tray Alarm Board) - 1 per tray

#T-6W3F-10
Test Cord for 36B Cabinet,
Protector / 526A plug to 125 Station Protector (10')
 - 1 per cabinet

return to top



6 Position Environmental Control Unit (ECU) for Marconi Cabinet



12

Marconi ECU Cabinet Solutions (.pdf)

 # TFC-MARC6-01
 6 Position Environmental Control Unit (ECU) for Marconi Cabinet
(supports 6 HX fans)

Includes: (2) Temperature Sensors

return to top
