NEW CO Replacement Fans
TAG Central Office Replacement Fans

Description:

32 Page booklet w/ NEW Central Office
Replacement Fans provided by TAG, Inc.

Last Update: 09/22/17, (Rev.11)



NEW Replacement Fans
TAG Replacement Fans

Description:

58 Page booklet w/ NEW Replacement Fans
for Central Office & OSP applications
provided by TAG, Inc.

Last Update: 12/04/17, (Rev.81)


  5ESS Fans



5ESS       KS22501L3 MODELS

# TF-5ESS-01F
5ESS
Replacement Fan (KS22501L3)
w/ 3 Leads and Faston Connectors
(fan w/ power prongs)


# TF-5ESS-01P
5ESS
Replacement Fan (KS22501L3)
w/ 3 Leads and AMP Connector
(fan w/ power prongs)

5ESS       KS23912L1A MODELS

KS23912L1A

# TF-5ESS-02F
5ESS
Replacement Fan (KS23912L1A)
w/ 5 Leads and Faston Connectors
(w/ Internal Thermal Speed Control Sensor)


KS23912L1A

# TF-5ESS-02P
5ESS
Replacement Fan (KS23912L1A)
w/ 5 Leads and Amp Connector
(w/ Internal Thermal Speed Control Sensor)

5ESS         KS23912L2 MODEL

KS23912L2

# TF-5ESS-03P
5ESS
Replacement Fan (KS23912L2)
w/ 4 Leads and Amp Connector

5ESS      KS22501L3A MODELS

KS22501L3A

# TF-5ESS-04F
5ESS
Replacement Fan (KS22501L3A)
w/ 5 Leads and Faston Connectors


KS22501L3A

# TF-5ESS-04P
5ESS
Replacement Fan (KS22501L3A)
w/ 5 Leads and Amp Connector

5ESS        KS23398L2 MODEL

5ESS ISLU Replacement Fan (KS23398L2)

# TF-5ESS-10P
5ESS ISLU
Replacement Fan(KS23398L2)
48V Square Fan w/ 5 Leads and AMP Connector



   return to top

  Adtran Fans


ADTRAN TA5000


# TF-TA5K-01
Adtran TA5000,
48 Volt Replacement Fan
w/ 4 Wire Molex Plug





ADTRAN TA5000


# TF-TA5K-02
Adtran TA5000, 48 Volt Replacement Fan
w/ 3 Wire Molex Plug



   return to top

  Alcatel Fans

Alcatel 1000/7300 48 Volt Replacement Fan w/ Tach Output


ALCATEL 1000/7300


# TF-ALC-01
Alcatel 1000/7300,
48 Volt Replacement Fan
w/ Tach Output
(use in 3EC 15478 (XXXX) & 3EC 37933 (XXXX) fan trays)



Alcatel 7300 48 Volt Replacement Fan


ALCATEL 7300


# TF-AL7300-02
Alcatel 7300,
48 Volt Replacement Fan
w/ Internal Sensor & Tach Output
(use in 3EC 16697 (XXXX) fan trays)



DSC / Alcatel ECS1 48 Volt Replacement Fan


DSC / ALCATEL ECS1


# TF-DSCECS1-01
DSC / Alcatel ECS1,
48 Volt Replacement Fan




Alcatel 1631 48 Volt Replacement Fan (square)


ALCATEL 1631


# TF-ALC1631-01
Alcatel 1631,
48 Volt Replacement Fan (square)
w/ Power Prongs
(use in Blower Assembly # 695-3363-302)





ALCATEL 1631


# TF-ALC1631-02
Alcatel 1631,
48 Volt Replacement Fan (round)
w/ Power Prongs, Unterminated Tach Lead & (1) Butt Splice
(use in Blower Assembly # 3AL45446AA)



   return to top

  BigBand Fans

BIGBAND

# TF-BIGBND-01
BigBand 12 Volt 3 Wire Open End Replacement Fan
w/ Speed Control

# TF-BIGBND-03SR
BigBand Shelf / Door Repair
TAG repair service - includes: (3) PN # TF-BIGBND-01 Fans


BigBand 12 Volt Power Supply Replacement Fan

BIGBAND FTTP

# TF-BIGBPS-01
BigBand 12 Volt Power Supply Replacement Fan (40mm)
w/ 3 Wire Molex Plug (use in FTTP bays)

   return to top

  Ciena Fans

Ciena 1600 DWDM 48 Volt Replacement Fan

CIENA 1600

# TF-CN1600-01
Ciena 1600 DWDM 48 Volt Replacement Fan
(fan only, mounting bracket is not included)


Ciena DN7100 12 Volt Replacement Fan (SMALL)

CIENA DN7100

# TF-DN7100-01
Ciena DN7100 12 Volt Replacement Fan
w/ 3 Wire Molex Plug
(Small Fan, Equiv. to TA225DC)


Ciena DN7100 12 Volt Replacement Fan (MEDIUM)

CIENA DN7100

# TF-DN7100-02
Ciena DN7100 12 Volt Replacement Fan
w/ 3 Wire Molex Plug
(Medium Fan, Equiv. to TA300DC)

   return to top

  Cisco Fans

Cisco ONS 15454 48 Volt Replacement Fan

CISCO 15454

# TF-C15454-01
Cisco ONS 15454 48 Volt Replacement Fan
w/ 3 Wire Right Angle Connector


(use in CISCO ONS 15454 Fan Tray # 800-21448-02, HECI: WMMYAFEGAA)

   return to top

  DEX600E Fans

DEX600E MSP 48 Volt Replacement Fan


DEX600E MSP


# TF-DEXLAP-01
DEX600E MSP
48 Volt Replacement Fan

(Equiv. to 155-2936-055 LAP Fans)




DEX600E CS3 48 Volt Replacement Fan


DEX600E CS3


# TF-DEXCS3-01
DEX600E CS3
48 Volt Replacement Fan




DEX600E DSI 48 Volt Fan Replacements


DEX600E DSI


# TF-DEXDSI-01
DEX600E DSI
48 Volt Replacement Fan
(Fan Assembly w/ Mounting)

(Equiv. to 500-0000-294 fans for DSI (FAIC) type cards)




DEX600E DTI 48 Volt Fan Replacements


DEX600E DTI


# TF-DEXDTI-01
DEX600E DTI
48 Volt Replacement Fan
(Fan Assembly w/ Mounting)

(Equiv. to 400-0063-900 fans for DTI (AMM) type cards)



  return to top

  GTD-5 Fans

GTD-5 48 Volt Replacement Fan


GTD-5


# TF-GTD5-01
GTD-5 48 Volt Replacement Fan
w/ 5 Wire Molex Plug



   return to top

  Kentrox Fans

Kentrox AISwitch Series 180 Replacement Fan


KENTROX AISWITCH


# TF-AI-180
Kentrox AISwitch Series 180
48 Volt Replacement Cooling Fan
w/ 3 Wire Right Angle Connector
(used in AICOOL-48 fan unit)



  Lorain Marconi Rectifier Fans

  RHM-400/800 Rectifier Unit (Lorain / Marconi) 230VAC Replacement Fan


LORAIN / MARCONI RECTIFIER

# TF-RHM400-01
RHM-400/800 Rectifier Unit (Lorain / Marconi)
230VAC Replacement Fan
(use in RHM400D50 & RHM800E50 Rectifier Units)





New TAG Fan Tray Assembly for Vortex Rectifier (Lorain / Marconi 104545)


# TFT-MRECT
TAG Fan Tray Replacement - New TAG Fan Tray Assembly for Vortex Rectifier (Lorain / Marconi 104545)

Includes: (1) NEW Fan Tray & (3) NEW 24 Volt Replacement Fans w/ Wiring Harness & Connector

(Used in Vortex V200D50 Power Conversion Unit, HECI: PBP1FT0DAA, replaces Nidec Model # T34874-MAR)



LORAIN / MARCONI VORTEX V200E50


# TF-MRECT-02
Vortex Rectifier (Lorain / Marconi)

24 Volt Replacement Fan
w/ 4 threaded mounting locations & 3 Wire Molex Plug

(Used in Vortex V200E50 Power Conversion Unit, HECI: PBPUG0V2AA (fan only - use with existing metal housing)


   return to top

  Lucent Fans (CBX500, DDM-2000, METROPOLIS DMX, FT-2000, DACS III / IV)

CBX 500 OCD 12 Volt Replacement Cooling Fan

CBX 500* OCD

# TF-CBX500-01
CBX 500 OCD
12 Volt Replacement Cooling Fan


*CBX 500 is a registered trademark of Alcatel-Lucent.


DDM-2000 24 VOLT FAN REPLACEMENT KIT

DDM-2000*

# TF-DDM201-KIT1
DDM-2000*
24 Volt Fan Replacement Kit w/ Mounting Plate

*DDM-2000 is a registered trademark of Alcatel-Lucent.


DDM-2000 48 Volt Fan Replacement Fan

DDM-2000*

# TF-DDM202
DDM-2000*
48 Volt Fan Replacement Fan

(for use in Nidec T35078-LUC 440233, Lucent Comcode: 408741205) (fan only, mounting bracket is not included)

*DDM-2000 is a registered trademark of Alcatel-Lucent.


Metropolis DMX 48 Volt Replacement Fan


METROPOLIS DMX*


# TF-DMXMET-01
Metropolis DMX 48
Volt Replacement Fan

*Metropolis DMX is a registered trademark of Alcatel-Lucent.



FT-2000*

# TF-FT201
Lucent Fiber Terminal 2000 (FT-2000) 48 Volt Replacement Fan

*FT-2000 is a registered trademark of Alcatel-Lucent.


Lucent DACS III / IV 48 Volt Replacement Fan


DACS III / IV*

# TF-DACS3/4-01
Lucent DACS III / IV 48 Volt Replacement Fan
w/ 4 Wire Molex Plug

(Equiv. to KS23913L1), Used in Lucent Fan Assemblies: DACS III (ED-2C816-30, G1 or ED-2C906-30) DACS IV (WP92310L4)



Lucent DACS III / IV 48 Volt Replacement Fan


DACS III / IV*

# TF-DACS3/4-02
Lucent DACS III / IV 48 Volt Replacement Fan
w/ 5 Wire Molex Plug

(Equiv. to KS23913L1), Used in Lucent Fan Assemblies: DACS III / IV (WP91473-L3B)

*DACS III & DACS IV are registered trademarks of Alcatel-Lucent.


   return to top

  NEC Fans

NEC FD-31201A / FD-32401A Replacement Fan


NEC

for NEC FD-31201A / FD-32401A LINE TERMINATING MULTIPLEXER UNIT

# TF-NEC-01
NEC
48 Volt Replacement Fan (fan only)


# TF-NEC01-KIT1
NEC 48 Volt Replacement Fan Kit w/ Mounting Plate & Guard Grill



NEC ITS-2400 Replacement Fan


NEC

for NEC ITS-2400 INTELLIGENT TRANSPORTER

# TF-NEC-02
NEC 48 Volt Replacement Fan (fan only)

# TF-NEC02-KIT1
NEC 48 Volt Replacement Fan Kit w/ Mounting Plate & Guard Grille



ITS-2400V FL Replacement Fan

NEC
for NEC ITS-2400V FL INTELLIGENT TRANSPORTER


# TF-NEC-03*
NEC
48 Volt Replacement Fan (fan only)
* fan is used with existing hardware

  return to top



  Nortel Fans (DMS, Carrier VoIP)

DMS-100 48 Volt Replacement Fans & Sensors


DMS-100


# TF-DMS01
DMS-100
48 Volt Replacement Fan
(use in NT3X9013 fan trays)

# TF-DMS01S
DMS-100
Replacement Fan Sensor
(use in NT3X9013 fan trays)



DMS-1U 48 VOLT FAN REPLACEMENTS


DMS-1U


# TF-DMS02 (.pdf)
DMS-1U
48 Volt Fan Replacement
w/ 4 clear, unthreaded mounting holes

(use in NT3X9013 fan trays)



Nortel DMS-100 NT3X90AA 24VAC to 48V Fan Tray Conversion Kit


DMS-100 24VAC to 48VDC Fan Tray Conversion Kit


# TFT-DMS48KIT2
Nortel DMS-100 NT3X90AA 24VAC to 48VDC Fan Tray Conversion Kit


Includes:
(5) TF-DMS05P, DMS 48 Volt Replacement Fans w/ 2 Wire Molex Plug
(5) TF-DMS05S, DMS Replacement Fan Sensors
(1) Fan Control Board w/ Cabling, Mounting Hardware & Control Board Schematic
Frame Block Wiring Labels & Conversion Guide

Conversion Installation Guide (.pdf file)


   return to top


DMS-100 48 VOLT FAN REPLACEMENTS


DMS-100


# TF-DMS03
DMS-100
48 Volt Replacement Fan
w/ TTL Tach & 3 Wire Molex Plug




DMS 24 VAC FAN REPLACEMENTS


DMS 24VAC


# TF-DMS04AC
DMS-100 24 VAC
Fan Replacement w/ Power Prongs




DMS-10 48 Volt Replacement Fan


DMS-10


# TF-DMS10-01
DMS-10 48 Volt Replacement Fan w/ Power Prongs

# TF-DMS10S
DMS-10 Replacement Fan Sensor



DMS-100 NTRX91AA Fan Unit Replacement Fan


DMS-100


# TF-DMS-NTRX91
DMS-100
48V Replacement Fan
w/ 3 Wire Molex Plug

(use in DMS-100 NTRX91AA / NT0X91AA fan units
(MVIE and CSDM bays), CLEI: ENMYACM)



   return to top


Nortel IW SPM-IP 48 Volt Replacement Fan

CARRIER VoIP

# TF-DMS-FOS
Nortel IW SPM-IP 48 Volt Replacement Fan
for NTLX56AA Fan Assemblies

(used in Nortel IW SPM-IP NTLX55AA cooling units)

(fan only, arm assembly is not included)


Nortel / GENBAND Media Gateway 9000 Replacement Fan


CARRIER VoIP


# TF-MG9K-01
Nortel / GENBAND Media Gateway 9000
48 Volt Replacement Fan
w/ 3 Wire Molex Plug

(for use in NTNY18AA Cooling Unit)




TAG Refurbishing Service - Nortel DMS NT3X90(XX) Fan Tray
Customer Supplied Fan Tray -
w/
NEW Fans & Sensors


Nortel DMS NT3X90(XX) FAN TRAY REFURBISHING


# TF-DMS-05SR (CALL FOR INFORMATION)
TAG Refurbishing Service -
Nortel DMS NT3X90(XX) Fan Tray

(Customer Supplied Fan Tray)

Includes: (5) TF-DMS01, DMS 48 Volt Replacement Fan &
               (5) TF-DMS01S, DMS Replacement Fan Sensor




DMS DPCC SUPERNODE BLOWER "SQUIRREL CAGE"

# TF-DMSLGN5
DMS DPCC SuperNode Blower "Squirrel Cage" Replacement
w/ Internal Sensor (NT9X01BA & A0345301)



# TF-DMSLGN2
DMS DPCC SuperNode Blower "Squirrel Cage" Upgrade
(Customer Supplied Metal Housing, NT9X01BA & A0345301)

TAG Upgrade Service Includes:
NEW
“Squirrel Cage” w/ Integral Motor
NEW Control Box w/ Wiring Harness & Plug
NEW Air Flow Sensor (#TF-DMSLG01S)



  return to top

  OmniStar Fans

OMNISTAR

# TF-OMNISTAR-01
OmniStar, 12 Volt Replacement Fan (60mm)
w/ 2 Wire Plug

(fan only - use with existing guard grill)
(use in GI / Motorola OmniStar Chassis
w/ DC PS, # AM-Omni-CH CM1 DC48)




OMNISTAR GX2

# TF-GX2BTY-01
OmniStar GX2 (RPR), 5V Replacement Fan (25mm)
w/ 2 Wire Molex Plug



OMNISTAR GX2

# TF-GX2BTY-02
OmniStar GX2 (Laser), 5V Replacement Fan (25mm)
w/ 2 Wire Molex Plug


  return to top

  PathTrak Fans (JDSU)


PATHTRAK JDSU

# TF-HCU1500-01
JDSU PathTrak HCU 1500, 24V Replacement Fan
w/ 2 Wire Molex Plug


  return to top

  Siemens EWSD Fans

Siemens EWSD 48 Volt Replacement Fan


SIEMENS EWSD

# TF-EWSD-01
Siemens EWSD 48 Volt Replacement Fan
w/ Power Prongs
(fan only, use with existing guard grills)

Use in Siemens EWSD fan trays:
30050-B5681-X101-2
30050-X5681-X100-3-11
30050-B5681-X100-3-2


  return to top

  STP Ring Node

STP Ring Node Frame / Cabinet Replacement Fan

STP RING NODE

# TF-STPRN-01
STP Ring Node Frame / Cabinet
48 Volt Replacement Fan w/ 5 Wire Molex Plug
(fan only, use with existing guard grill)

(use in Lucent J3F011AE fan unit, HECI E5DYAAC)
(fan equiv. to PD48B3S4A)

  return to top

  Telco Systems (Edgelink Fans, M560)

Edgelink 100 Replacement Fans (40mm)


EDGELINK 100
40MM

# TF-EL100
Edgelink 100 Replacement Fan (40mm)

# TF-EL100DET
Edgelink 100 Replacement Detector PC Board

# TF-EL100-KIT2
Edgelink 100 Replacement Fan Kit (40mm)
includes: (1) TF-EL100 & (1) TF-EL100DET



Edgelink 100 Replacement Fan (35mm)


EDGELINK 100
35MM

# TF-EL100-02
Edgelink 100 Replacement Fan (35mm)



Telco Systems M560 Fiber Optic Terminal Replacement Fan


M560 FIBER OPTIC TERMINAL

# TF-TEL560-01
Telco Systems M560 Fiber Optic Terminal
48 Volt Replacement Fan
w/  Power Prongs & 4 Threaded Mounting Holes (screws included)


   return to top

  WaveStar Fans

WAVESTAR

# TF-WSTR-01
WaveStar TDM 10G
48 Volt Replacement Fan
w/ 3 Wire Molex Plug

  Wideband 3190 Fans

Wideband 3190 48 Volt Replacement Fan



WIDEBAND 3190

# TF-WB3190
Wideband 3190
48 Volt Replacement Fan
w/ 3 Wire Molex Plug


  return to top


TAG Home  l   Search TAG   l   2017 Catalog   l    Catalog Request

12/04/2017
